5-1
Bottom Bracket
Assembly Manual 09
4-1
Computer mount
Remove the bolt and cover.
Install the computer mount and
tighten the 2 bolts to 2 Nm.
Clean the inside of the frame BB & the BB cups with
isopropyl alcohol. Apply Loctite 641 on the grooves of
the both BB cups.
Install the cups into the frame with BRT-002 bearing
press from Enduro Bearings.
Install the provided Wheels MFG BBRight adapters if
using cranks with a 24mm spindle.
