FAFCO Sunsaver - Page 22

®
22
PHASE IV: Routine Maintenance
5
VRV:
Winter: Removed
Summer: Installed
4
End Caps:
6
Body
Straps
Isolation Valves:
Winter: “OFF”
Summer: “ON”
7
2 Automation:
Winter: “OFF”
Summer: “ON”
3 Drain Valves:
Winter: “Open”
Summer: “Closed”
1
Figure 13| Solar System Maintenance
Figure 13 depicts the components to decommission, remove or reinstall during sys-
tem Winterization, Summerization or when performing other routine maintenance.
