Specifications, Certifications & Listings
SunSaver
®
Collector Specifications
Collector Area 48ft
2
, 40ft
2
, 32ft
2
, 24ft
2
, 20ft
2
, 16ft
2
Collector Dimensions (HxWxD) 4ft x (12ft, 10ft, 8ft), 2ft x (12ft, 10ft, 8ft)
Weight (lbs empty)
22.0 (48ft
2
), 19.0 (40ft
2
), 16.0 (32ft
2
)
11.0 (24ft
2
), 9.5 (20ft
2
), 8.0 (16ft
2
)
Roof load (lbs full)
66.9 (48ft
2
), 58.9 (40ft
2
), 50.1 (32ft
2
)
33.4 (24ft
2
), 29.5 (20ft
2
), 25.1 (16ft
2
)
Fluid Capacity (gal)
5.4 (48ft
2
), 4.8 (40ft
2
), 4.1(32ft
2
)
2.7 (24ft
2
), 2.4 (20ft
2
), 2.1 (16ft
2
)
Fluid Connection Type
FAFCO
®
Proprietary
Chemical Resistance Chlorine and Saline Pool Compatible
Freezing Drain at 45°F prior to Freezing Conditions
Absorptivity 0.96
Emissivity 0.90
Thermal Specifications*
Thermal Energy Output 1800 Btu / (ft
2
-day)
System Operating Pressure (<100 °F) At Bottom Header 30 psi
System Intermittent Pressure (<100 °F) At Bottom Header 40 psi
Factory Test Pressure / Burst Pressure Per Collector 50 psi / 220 psi
Recommended Flow Rate Per Collector 0.1 gal/min/ft
2
Delta T (at y intercept)
6°F
Operating Temperature Range (typical) 60-100 °F
Stagnation Temperature 160°F
*All performance data calculated at STC (Standard Test Conditions) 80 °F, 317 Btu/hr./ft
2
, 1.5 AM, Inlet Water of 70 °F, Wind speed=3 mph
System Overview Cont’d
SunSaver
®
Collectors have been certified and listed for the following:
• SRCC OG-100 #10001954
• ICC-SRCC Listing #16006
