30
SAME END RETURN
REVERSE RETURN
SPLIT FEED / SPLIT RETURN
Various Plumbing Configurations & High Point Return
APPENDIX C — Reference Tables & Figures
Figure 16 | High Point Return Line
Multi-Bank SunSaver
®
Pool Systems utilize a common high point return line enabling each bank to have proportional feed and return line
backpressures which limits the water to favor the path of least resistance. Notice I) is an example of a stacked Reverse Return and II) is
stacked Same End Return.
I) STACKED REVERSE RETURN
II) STACKED SAME END RETURN
SPLIT FEED / REVERSE RETURN
