Control point
Sensor double heat source (only VT: MPDP-/ HPDP-/ FPDP;
VT7: PDFM-)
Indicator display of selected power
Indicator display of residual heat
Control point
Heat source for dishes (only VT: FPDP; VT7: PDFM)
Heat source position indicators
Heat source power selection sensors
from: 0....9
from: 9....0
Blocking control point
Blocking sensor
Sensor ON/OFF
HORIZONTAL CONTROL SENSORS
SENSOR DESCRIPTION
TYPE VT: MPDP-/ HPDP-/ MPGP-/ HPGP-
VT7:FPDM-
