Fagor “TOUCH CONTROL” - Page 11

58
Control point
Sensor double heat source (only VT: MPGP-/HPGP-)
Indicator display of selected power
Indicator desplay of residual heat
Heat source selection heat source
Heat source power selection sensors
from 0....9
from 9....0
Blocking control point
Blocking sensor
Sensor ON/OFF
SENSOR DESCRIPTION
TYPE VT: MPDP-/HPDP-/MPGP-/HPGP-
COMPACT HORIZONTAL CONTROL SENSORS
