Fagor “TOUCH CONTROL” - Page 12

Control point
Sensor double heat source (only VT: MPDP-/HPDP-)
Indicator display of selected power
Indicator desplay of residual heat
Heat source position indicators
Heat source power selection sensors
from 0....9
from 9....0
Blocking control point
Blocking sensor
Sensor ON/OFF
SENSOR DESCRIPTION
TYPE VT: MPDP-/HPDP-/MPGP-/HPGP-
COMPACT VERTICAL CONTROL SENSORS
59
