Section 1: General Information
Figure 4
Sample Container Area
Figure 5
Sample Container Area Lines Note that the
sample-in line is longer than the aeration line.
Sample input
lineassembly
400-105-020
Thermocouple
- fuel sample
650-009-055
Beaker, 1000 ml
648-400-012
Aeration line
assembly
400-105-002
Sample output
line assembly
400-105-028
Beaker, 1000 ml
648-400-012
Aeration line
assembly
400-105-002
Sample output
line assembly
400-105-028
Sample input
lineassembly
400-105-020
