Fuel heater tube holder
output line assembly
400-105-005
Bypass Line (part of
heater tube holder
assembly)
Upper insulation bushing
400-018-003
Heater Tube Holder
Assembly Hex Nut
977-438-001
Lower insulation bushing
400-018-003
DP Filter Housing
(part of heater tube
holder assembly)
Heater tube holder
assembly
400-103-009
Lower insulation bushing
400-018-003
Upper insulation bushing
400-018-003
O-ring
650-008-002
O-ring
650-008-002
Heater Tube Holder
Assembly Hex Nut
977-438-001
Figure 8
Components For Assembly of Prelter
Figure 7
Components For Assembly of Test Section Area
Lower Pre-Filter Cover Assembly
400-105-014
Upper Pre-Filter Cover Assembly
400-105-021
O-ring Pre-Filter
620-210-001
Fuel heater tube holder
input line assembly
400-105-004
Pre-Filter filter paper
648-400-005
Pre-Filter Screws
870-190-063
Metal Pre-Filter screen
400-027-003
