FALMEC line User Manual

ENGLISH
17
Phase E page 5
• Slide the extension (H) until it is positioned at the desired height (Fig.
1
).
• Following what is indicated in Fig.
2
, draw a line on the wall that will be used to position the bracket (L) correctly.
• Place the bracket (L) on the wall by following the line drawn on it. With a spirit level, check the horizontal alignment and mark the 2 drilling points
at the ends (Fig.
3
).
• Drill the holes, insert 2 expansion plugs (ø 6mm) and fasten the bracket (L) with the relative screws (V4) (Fig.
4
).
• Tighten the extension (H) to the bracket (L) using screws (V5) (Fig.
5
).
• Electrically power the hood in accordance with regulations in force.
OPERATION
WHEN SHOULD THE HOOD BE SWITCHED ON AND OFF?
Switch on the hood at least one minute before starting to cook: this enhances the airflow to convey fumes and vapours towards the suction surface.
After cooking, leave the hood operating until complete extraction of all vapours and odours. If required, by means of the Timer function, it is possible
to set hood auto switch-off after 15 minutes of operation.
WHICH SPEED IS TO BE SELECTED?
The rst speed is a low consumption energy-saving way of keeping the air clean, the second speed is used in normal conditions, and the third
speed is used when there are strong odours and vapours.
WHEN SHOULD THE FILTERS BE WASHED OR REPLACED?
The hood is assembled with two different types of filters: metal ones (washable) and active carbon ones (non-washable). The former must be cleaned every 30 hours
of use, the latter are to be replaced every 3-4 months, depending on the use of the hood. For further information, please read the chapter regarding "Maintenance"
on page 18.
USE OF MECHANICAL PUSH BUTTON CONTROL PANEL
OFF 1 2 3
Light button
Press this button to turn the hood light on (button pressed in)
or off (button out)
1
Button 1: Press this button (button in) to start or set the motor
at minimum speed
2
Button 2: Press this button (button in) to start or set the motor
at medium speed
OFF
OFF button
Press this button to switch the motor off
3
Button 3: Press this button (button in) to start or set the motor
at maximum speed
LIGHTING
The range hood is equipped with high efficiency, low consumption LED spotlights with extremely long duration under
normal use conditions.
Should the LED spotlight need to be replaced, proceed as shown in the figure
H on page 6.
600
m
3
/h

FALMEC line Specifications

General

Pressure (Pa)	420
Number of speeds	4
Type of extraction	-
Noise level (low speed)	44 dB
Maximum extraction power	800 m³/h
Noise level (high speed)	67 dB
Minimum distance from electric hob	600 mm
Type	Wall-mounted
Control type	Buttons
Product color	Stainless steel
Motor included	Yes
Built-in display	No
Exhaust location	Top
Exhaust connection diameter	150 mm
Bulb power	1.2 W
Number of bulbs	2 bulb(s)
Grease filter type	Charcoal
Motor power	243 W

Weight and Dimensions

Depth	450 mm
Width	900 mm
Weight	18000 g
Height (max)	1100 mm
