FALMEC Move User Manual

2
11" 7/8 - 303mm
23" 4/8 - 598 mm
22" 1/8 - 561 mm
10" 3/8
264mm
58mm
2"2/8
2" 7/8
73mm
4" 1/8
105mm
7" 5/8 - 195 min.
9" 5/8 - 245 max.
17" 4/8 - 443 min.
19" 3/8 - 493 max.
10" 5/8 - 270mm
1/2 - 13mm min.
2" 4/8
63mm
max.
5/8
17mm
11" 6/8 - 300mm min.
13" 6/8 - 350mm max.
Ø 5" 13/16
147 mm
ø8 mm
ø6 mm
MOVE 24"
FDMOV24W5SB
FDMOV24W5SW
120Vac 60HZ, 300W 30lb - 14 kg
EN- tool required
FR- outil requis
ES- herramienta requerida
IT - Attrezzi necessari
EN- cable length 5,0ft (1,5m)
FR- longueur de câble 5,0ft (1,5m)
ES- longueur de câble 5,0ft (1,5m)
IT- lunghezza cavo 5,0ft (1,5m)

FALMEC Move Specifications

General

Motor power	215 W
Connected load	280 W
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A+++ to D
Annual energy consumption	67 kWh
Noise level	62 dB
Pressure (Pa)	500
Number of speeds	4
Type of extraction	-
Noise level (low speed)	49 dB
Maximum extraction power	800 m³/h
Noise level (medium speed)	56 dB
Grease filtering efficiency class	C
Minimum distance from electric hob	520 mm
Removable filter	Yes
Number of filters	4 pc(s)
Grease filter type	Metal
Type	Built-in
Product color	Black
Exhaust connection diameter	150 mm
Bulb power	1.2 W
Number of bulbs	3 bulb(s)
Package depth	465 mm
Package width	1295 mm
Package height	410 mm
Package weight	24100 g

Weight and Dimensions

Depth	277 mm
Width	1161 mm
Weight	20000 g
Height (max)	696 mm
Height (min)	336 mm
Height without chimney	73 mm
