20
The next appearing menu ‘function test’ will display the attached Fanatec
®
Steering Wheel. In this example a CSL Elite Steering Wheel (PS4
TM
version) is
shown below:
This window provides a lot of diagnostic information and gives the option to test
the hardware and peripherals:
Indicator bar shows the current steering wheel
position, the upper box shows the position in
digits, the lower box shows the position as an
angle (positive and negative angle related to
the calibrated wheel center position).
The button ‘display test’ activates a signal ow on the LED display of the at-
tached Fanatec
®
steering wheel and activates all LED display segments so you
can check if all LED display segments work properly.
The button ‘FFB test’ starts a force feedback test and activates the motor of the
CSL Elite Racing Wheel to check proper functionality.
The button ‘Wheel Base RevLEDs test’ starts a signal ow on the LED bar on
the upper frontside of the CSL Elite Wheel Base and activates them to test
proper functionality of each single LED.
*PC compatibility not tested nor endorsed by Sony Interactive Entertainment LLC.
