Fantec QB-35US3R - Page 7

Blue / Active
Purple / Transferring Data
Blue / Active
Purple / Transferring Data
LED Display Status
LED Display Status
EN - 11/28
Mirroring
RAID 1
When any of HDD1 ~ HDD4 is recognized by the PC,
HDD1 ~ HDD4 blue / active is on.
MODE LED Display
RAID 3
Striped set
with dedicated parity
MODE LED Display
When any of HDD1 ~ HDD4 is recognized by the PC,
HDD1 ~ HDD4 blue / active is on.
Red / Rebuild
When the data is being rebuilt, LED
of rebuild, HDD error and HDD
(1-4, depends on which HDD
is being rebuilt) error will be on.
Red / Rebuild
When the data is being rebuilt, LED
of rebuild, HDD error and HDD
(1-4, depends on which HDD
is being rebuilt) error will be on.
EN - 12/28
