fantech
Recommended Maintenance
1. Since fan bearings are sealed and provided with an internal lubricating material, no additional lubrication is necessary.
2. Fan impeller may accumulate lint. Periodic inspection, based upon dryer usage, should be performed to ensure that the fan impeller is not
obstructed or loaded with lint. Under normal conditions, fan should be inspected a minimum of every Six (6) Months. Note: Excessive booster fan
noise or vibration may be an indication of lint buildup on the impeller. To inspect and clean the impeller:
a. Disconnect the incoming power supply at the source.
b. Remove the duct from the fan inlet and remove any lint buildup on the impeller.
c. Reconnect the duct to the fan. Turn power supply on.
Troubleshooting
Prior to performing Steps 1 - 3, be certain that the electrical supply to the fan/switch is turned off.
If fan fails to start when the dryer cycle begins, please follow the procedure listed below:
1. Check the incoming supply for proper voltage.
2. Turn on the electrical supply and restart the dryer cycle. Check to be certain that fan starts.
If fan still fails to start after performing Steps 1 - 4, continue following the procedure as listed below:
3. Verify that the pressure switch diaphragm is vertical as illustrated on Page 2 of these instructions. If the diaphragm is not vertical, reposition the
pressure switch and check for fan operation against another dryer cycle.
4. Verify that the tubing is not crimped and that the tubing connector
nipples are not obstructed.
5. If switch diaphragm is vertical and fan still fails to start, with the electrical supply on:
a. Remove the tubing from the nipple on the fan and blow gently into the tubing for a period of 5 to 10 seconds.
b. The fan should start to operate within the 5 to 10 second period.
c. If fan fails to start, please consult Fantech for additional
technical support.
