79
MAINTENANCE
IT
EN
DE
FR
ES
REAR-VIEW MIRRORS
The operations described below apply to both rear-
view mirrors.
Place the vehicle on the kickstand and on a flat and stable
surface. Loosen the lock nut “A”, turn the left-hand mirror
counter-clockwise and remove it, then turn the right-hand
mirror clockwise and remove it.
During reassembly, before tightening the nut, check
that the mirror support rod is aligned with the
handlebar.
Rear-view mirror adjustment
To adjust the rear-view mirrors, get on the vehicle in the
driving position and turn the rear-view mirror according to
your needs. It is also possible to adjust the inclination of the
rear-view mirror support rod. To carry out this operation,
loosen the screw “B” and move the support rod sideways.
Adjust and tighten screw “B”.
B
A
