Fanvil i12 Manual

Fanvil Technology Co. Ltd
Addr:10/F Block A, Dualshine Global Science Innovation Center, Honglang North 2nd Road, Bao'an District, Shenzhen, China
Tel: +86-755-2640-2199 Email: sales@fanvil.com support@fanvil.com Official Web:www.fanvil.com
2. Operation Guide
First, you need to prepare the environment, then you should get you device into post mode. Finally
you can update your device through tools in your computer. Please check the following steps for
detail.
2.1. Prepare the environment
Step1.
Refer to the connection diagram, connect the computer and Fanvil industry products to the same
PoE switch with Network cable.
Step2.
Add IP address 192.168.10.X for example 192.168.10.2 on the PC.
(IP address between 192.168.10.2-192.168.10.254 is ok)
Step3.
Download the new version you want to update, and save it in your computer. For example:
D:\333\iSeries2.8.2.7009T20210531154501.z
Step4.
Prepare FTP server and load the update file:
① Click http://download.fanvil.com/HowTo/UpdateInPostMode/wftpd32.rar to download
wftpd32.exe, and open WFTPD.exe, click Security and select Users/rights.

Fanvil i12 Specifications

General

Operating temperature (T-T)	-40 - 70 °C
Certification	CE/FCC
Buttons quantity	1
Networking standards	IEEE 802.1x, IEEE 802.3af
Connectivity technology	Wired
Power over Ethernet (PoE)	Yes
Supported network protocols	SIP2.0 UDP/TCP/TLS, RTP/RTCP/SRTP, STUN, DHCP, 802.1x, L2TP, OpenVPN, SNTP, FTP/TFTP, HTTP/HTTPS, Tr069
International Protection (IP) code	IP65
Indoor unit included	-
Outdoor unit power type	AC/DC
Placement	Wall
Product color	Aluminum

Weight and Dimensions

Depth	39 mm
Width	195 mm
Height	120 mm
Package depth	62 mm
Package width	260 mm
Package height	165 mm
Package weight	850 g
