Fanvil PA3 User Manual

34
Static IP
Network parameters must be entered manually and will not change. All
parameters are provided by the ISP.
DHCP
Network parameters are provided automatically by a DHCP server.
PPPoE
Account and Password must be input manually. These are provided by
your ISP.
If Static IP is chosen, the screen below will appear. Enter values provided by the ISP.
DNS Server
Configured
by
Select the Configured mode of the DNS Server.
Primary DNS
Server
Enter the server address of the Primary DNS.
Secondary
DNS Server
Enter the server address of the Secondary DNS.
attention：
1）After setting the parameters, click【Apply】to take effect.
2）If you change the IP address, the webpage will no longer responds, please enter the
new IP address in web browser to access the device.
3）If the system USES DHCP to obtain IP when device boots up, and the network
address of the DHCP Server is the same as the network address of the system LAN,
then after the system obtains the DHCP IP, it will add 1 to the last bit of the network
address of LAN and modify the IP address segment of the DHCP Server of LAN. If the
DHCP access is reconnected to the WAN after the system is started, and the network
address assigned by the DHCP server is the same as that of the LAN, then the WAN
will not be able to obtain IP access to the network
9.10Network >> service port
This page provides the settings of webpage login protocol, protocol port and RTP port.

Fanvil PA3 Specifications

General

DHCP server	Yes
Supported protocols	SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS RTP/RTCP/SRTP STUN DHCP IPv6 PPPoE L2TP OpenVPN SNTP FTP/TFTP HTTP/HTTPS TR-069
VPN support	L2TP / OpenVPN
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Package depth	58 mm
Package width	147 mm
Package height	114 mm
Input current	2 A
Input voltage	12 - 24 V
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Mounting type	Desktop/Wall mounting
Product color	Black
LED indicators	Status
Control display unit	-

Weight and Dimensions

Depth	31 mm
Width	125 mm
Height	84.2 mm
