19
LW-401 Operation, Installation, and Maintenance ManualLW-401
Level 6-4 - Set Simplified Zone Code
Rounds
1. The selected number of rounds is shown
by the red zone LEDs as indicated in the
following table:
Zone 3 LED = 3 rounds
Zone 4 LED = 4 rounds
Zone 5 LED = 5 rounds
Zone 6 LED = 6 rounds
Zone 7 LED = 7 rounds
Zone 8 LED = 8 rounds
2. Press the Reset key to advance the
pointer (yellow zone LED) to the desired
time.
3. Press the Drill key to activate the
desired time.
4. Press the ACK key when done.
Program Level 7 - Set System
Password
1. Press the Reset key 7 times to select
Program Level 7.
2. Press the Silence key to select the
Password digit to be programmed.
Example: 7-1 programs the first digit of
your password.
3. The selected digit choice is shown by the
red zone LED as indicated in the
following table:
Zone 1 LED = ACK (1)
Zone 2 LED = RESET (2)
Zone 3 LED = DRILL (3)
Zone 4 LED = SILENCE (4)
4. Press the Reset key to advance the
pointer (yellow zone LED) to the desired
digit choice.
5. Press the Drill key to activate the
desired digit choice.
6. Press the Silence key to select another
digit to be programmed and return to
Step 3.
7. Press the ACK key when done.
Program Level 8 - Set the AC Fail
Signal Delay
1. Press the Reset key 8 times to select
Program Level 8.
2. Press the Silence key to select this
programming function. There is no other
function to be selected.
Note: 8-1 programs the AC Fail Signal
Delay.
3. A six-hour delay is activated when the
red zone LED for zone 1 is on. If the LED
is off, there is no delay.
4. Press the Drill key to activate or
deactivate the delay.
5. Press the ACK key when done.
Program Level 9 - Enable System
Option Cards
1. Press the Reset key 9 times to select
Program Level 9.
2. Press the Silence key to select this
programming function. There is no other
function to be selected.
Note: 9-1 enables the System Option
Cards.
3. The selected Option Cards are shown by
the red zone LED as indicated in the
following table:
Zone 1 LED = LWZR-8 Enabled
Zone 2 LED = LWRA-8B/W, Addr 1 Enabled
Zone 3 LED = LWRA-8B/W, Addr 2 Enabled
Zone 4 LED = LWCT-1 Enabled
Zone 5 LED = Zone Expansion Enabled
