LW-401 Operation, Installation, and Maintenance ManualLW-401
TABLE 7
PROGRAMMING SHEET
Level Sublevel Description
1 1 Initiating Device Circuit Zone 1 Enabled Bypassed
2 Initiating Device Circuit Zone 2 Enabled Bypassed
3 Initiating Device Circuit Zone 3 Enabled Bypassed
4 Initiating Device Circuit Zone 4 Enabled Bypassed
5 Initiating Device Circuit Zone 5 Enabled Bypassed
6 Initiating Device Circuit Zone 6 Enabled Bypassed
7 Initiating Device Circuit Zone 7 Enabled Bypassed
8 Initiating Device Circuit Zone 8 Enabled Bypassed
2 1 Optional LWZE-4A/LWZE-8A/LWZR-8 Output 1 Enabled Bypassed
2 Optional LWZE-4A/LWZE-8A/LWZR-8 Output 2 Enabled Bypassed
3 Optional LWZE-4A/LWZE-8A/LWZR-8 Output 3 Enabled Bypassed
4 Optional LWZE-4A/LWZE-8A/LWZR-8 Output 4 Enabled Bypassed
5 Optional LWZE-4A/LWZE-8A/LWZR-8 Output 5 Enabled Bypassed
6 Optional LWZE-4A/LWZE-8A/LWZR-8 Output 6 Enabled Bypassed
7 Optional LWZE-4A/LWZE-8A/LWZR-8 Output 7 Enabled Bypassed
8 Optional LWZE-4A/LWZE-8A/LWZR-8 Output 8 Enabled Bypassed
3 1 Zone 1 Initiating Verified Supervisory Generic
2 Zone 2 Initiating Verified Supervisory Generic
3 Zone 3 Initiating Verified Supervisory Generic
4 Zone 4 Initiating Verified Supervisory Generic
5 Zone 5 Initiating Verified Supervisory Generic
6 Zone 6 Initiating Verified Supervisory Generic
7 Zone 7 Initiating Verified Supervisory Generic
8 Zone 8 Initiating Verified Supervisory Generic
4 1 NAC 1 Steady Temporal March SZC Non-Silenceable
2 NAC 2 Steady Temporal March SZC Non-Silenceable
5 1 IDC 1 Output 1 2 3 4 5 6 7 8
2 IDC 2 Output 1 2 3 4 5 6 7 8
3 IDC 3 Output 1 2 3 4 5 6 7 8
4 IDC 4 Output 1 2 3 4 5 6 7 8
5 IDC 5 Output 1 2 3 4 5 6 7 8
6 IDC 6 Output 1 2 3 4 5 6 7 8
7 IDC 7 Output 1 2 3 4 5 6 7 8
8 IDC 8 Output 1 2 3 4 5 6 7 8
6 1 Retard Reset Timer 15 20 25 30 40 50 50 50 seconds
2 Inhibit Timer 0 6 30 60 90 120 180 300 seconds
3 Cutoff Timer 0 1 2 5 10 15 20 25 minutes
4 Zone Code Round Count (3 to 8)=
7 1 Password Digit 1 =
2 Password Digit 2 =
3 Password Digit 3 =
4 Password Digit 4 =
8 1 AC Fail Signal Delay 0 Hours 6 Hours
9 1 LWZR-8 Enabled #1 LWRA-8B/W Enabled #2 LWRA-8B/W Enabled
LWCT-1 Enabled LWZE-4A/LWZE-8A Enabled
