Faraone ELEVAH 40 MOVE - Controls at the Base (Optional)

USE AND MAINTENANCE MANUAL - SECTION 4
ELEVAH 40 MOVE / 40 B AERIAL PLATFORM – Rev. 12_2021
Page 4-16
CONTROLS AT THE BASE (OPTIONAL)
1. Selector enabling base controls/controls in the cage;
2. Cage up/down control.
General information
Before operating the machine from the base control desk, the following conditions of the controls
must be met:
• The battery voltage must be sufficient to operate the machine.
• Console in the cage – The emergency stop switch with removable key must be in the RESET
position.
• Console at the base – The control enabling selector on the base/cage must be in the
appropriate position.
Controls selector on the base/in the cage
CONTROLS IN CAGE mode
TURN the selector to the RIGHT to enable the controls in the CAGE.
CONTROLS AT BASE mode
TURN the selector to the LEFT to enable the controls at the BASE.
Cage up/down control
TURN the selector to the LEFT to LOWER the cage.
TURN the selector to the RIGHT to RAISE the cage.
CAUTION
DO NOT USE THE CONTROLS AT THE BASE WHEN THE OPERATOR IS IN THE CAGE
1
2
