Faraone ELEVAH 40 MOVE - Attached Documentation; ATTACHMENT 1 - Layout for Decal Application

USE AND MAINTENANCE MANUAL – SECTION 9
ELEVAH 40 MOVE / 40 B AERIAL PLATFORM – Rev. 12_2021
Page 9-1
SECTION 9. ATTACHED DOCUMENTATION
ü ATTACHMENT 1 – Layout for decal application;
ü ATTACHMENT 2 - Fluid power layout;
ü ATTACHMENT 3 – Electrical layout - ELEVAH 40 MOVE;
ü ATTACHMENT 4 – Electrical layout - ELEVAH 40 B;
ü ATTACHMENT 5 – Successful acceptance test certificate;
ü ATTACHMENT 6 – Declaration of conformity.
CAUTION
SHOULD THE MACHINE BE SOLD TO A THIRD PARTY, ALL DOCUMENTATION MUST BE
DELIVERED WITH IT.
ATTACHMENT 1 – Layout for decal application
Pos.
SYMBOL
DESCRIPTION
Pos.
SYMBOL
DESCRIPTION
1
DANGER SIGN
RISK OF FALLING OBJECTS
FROM ABOVE
2
PROHIBITION SIGN
DO NOT REMOVE THE SAFETY
GUARDS AND DEVICES
3
PROHIBITION SIGN
UNAUTHORISED PERSONNEL
MUST NOT USE THE
MACHINERY
4
OBLIGATION SIGN
REFER TO THE OPERATING
MANUAL
5
OBLIGATION SIGN
WEAR SAFETY SHOES
6
Max 200 kg
INDICATION
Maximum number of persons and
load on the cage
7
INDICATION
“BATTERY CHARGING
POSITION”
8
INDICATION
“RETAINING ONLY
1 PERSON”
9
INDICATION
“EMERGENCY DESCENT”
10
INDICATION
“EMERGENCY DESCENT
PROCEDURE”
11
INDICATION
OPENING THE ACCESS GATE
12
PLATE
CE plate
13
“GRIPPING POINT FOR MOVING
THE MACHINE”
(ELEVAH 40 B)
