USE AND MAINTENANCE MANUAL - SECTION 8
ELEVAH 40 MOVE / 40 B AERIAL PLATFORM – Rev. 12_2021
2. Insert the eight new pads (2 on each side) into the holes (2) made internally, at the base of the
second extension (part of the cage unit) and insert it all the way into the first extension;
3. Lift the machine with a forklift and retighten the nut that connects the cage unit/last extension to
the hydraulic cylinder and reposition the machine on the ground.
CAUTION
GREASE/LUBRICATE THE LIFTING COLUMN ONLY WITH "MOLYKOTE G-4500 FM"
GREASE OR PRODUCTS WITH THE SAME TECHNICAL CHARACTERISTICS.
CAUTION
FOR FURTHER INFORMATION REGARDING THE PURCHASE OF SPARE PARTS AND
CONSUMABLES, PLEASE CONTACT THE MANUFACTURER.
THE MANUFACTURER DISCLAIMS ALL LIABILITY FOR DAMAGE OR MALFUNCTION
CAUSED BY USE OF PARTS NOT AUTHORISED BY THE MANUFACTURER
