USE AND MAINTENANCE MANUAL - SECTION 2
ELEVAH 40 MOVE / 40 B AERIAL PLATFORM – Rev. 12_2021
BASIC CONSTRUCTION DATA
MACHINE FRAME: The frame of the machine (called base) is made completely of aluminium
profiles with rectangular sections. All essential components for normal machine operation in stable
conditions are installed on the frame.
EXTENSIBLE STRUCTURE: The extensible structure (column) consists of extruded galvanised iron
profiles (called extensions) that slide on each other by means of nylon pads.
An oil hydraulic cylinder is installed inside the column, synchronised on two rods, powered by the
hydraulic unit, to lift the structure.
CAGE, OBJECTS HOLDER TRAY AND OBJECTS HOLDER PLATFORM (optional): The cage,
the objects holder tray and the objects holder platform are entirely made of galvanised iron profiles.
The base platforms are built with 3 mm thick, non-slip, aluminium chequer plate.
EXPOSURE TO VIBRATION: The lifter does not produce vibrations that pose a risk to the health of
the operators. The weighted acceleration that the whole body is exposed to is less than 0.5 m/s
2
SOUND EMISSIONS: The A-weighted emission sound pressure level is below 70dB
REFERENCES TO STANDARDS
The machine has been manufactured in accordance with the health and safety requirements of
Machinery Directive 2006/42/EC and harmonised standard UNI EN 280:2015.
In accordance with the harmonised UNI EN 280:2015 standard, the Aerial Platform sample was
tested by the manufacturer using:
• Static stability tests
• Overload test
• Operation tests
The results of the tests and the conformity of the machine are reported in the document in Annex 5.
