USE AND MAINTENANCE MANUAL - SECTION 8
ELEVAH 40 MOVE / 40 B AERIAL PLATFORM – Rev. 12_2021
2. Lift the cage unit using a winch or other lifting equipment, completely extracting the second
extension (part of the cage unit) from the column and remove the eight pads (1) on it;
3. Remove all the pads (2) present (2 on each side) in the upper part of the first extension that
remain connected to the machine base;
4. Remove the old layer of grease and clean all the surfaces.
Installing new pads
1. Grease the seats of the pads on the extensions;
5. Insert two new pads, on each side, in the holes (1) made externally, at the top of the first
extension that remains connected to the machine base;
