WITHOUT C
OAX *
WITH
COAX
9
(GB- '99)
PuntoVirgola series
* MODY *
ERREP/R
* PROJECT *
PUNTOV
IRGOLA * SLIM
Installation of monitor onto the wall bracket.
U
P
J2 J3
Plugging in of monitor connectors to the terminal boards of wall bracket.
MONITORS
WB2160
Position for the intercommu-
nicating service.
Position for the audio privacy.
Audio privacy or intercommunicating service
Supplementary push-buttons installation
Taking out of button caps.
Inserting of extra buttons.
