STEP 4:
MOUNT FUEL SYSTEM
NOTE: Before installing fittings make sure to inspect for burs or flare
imperfections. When cutting fuel line make sure to blow out line to
keep debris from moving forward.
NOTE: Always use our dimension O-Ring for water separator, not doing
this could lead to priming issues.
A. Install 10-300 into the "E" port and 10-302 into the "T" port of the FASS, torque to 20 ft./
lbs. ***FITTINGS COME EQUIPPED WITH THREAD SEALANT, DO NOT USE THREAD TAPE***
Note: Ensure the 10-302 pointed towards the BHF-1002 with the "S" line on it. This will allow for best
fitting fuel supply line.
