STEP 4:
MOUNT FUEL SYSTEM
C. This hole punctures through the bed cross member. At the outside of the bed cross member there is an
opening, slide in the PFB-2001C with the RS-2001C as shown in figure 4-A.
Figure 4-A
D. Using the HEX Bolt 1/2-20x13/4"and the PFB-2002-S start the bolt into the hole threading into
PFB-2001C. Rubber isolator RS-2004 will be placed between the truck frame and the FASS bracket.
B. Locate the drivers side front bed mount, once this is done you will have a preexisting hole next to the
factory bed bolt. Using a 1/2 inch drill bit, drill out the preexisting hole.
