CRANE NOMENCLATURE
— Version with ground controls for crane and outriggers
— Version with top seat controls (fig. 4a) for crane by hand cables
(optional) (fig. 4)
Pos. Description
1 — Outrigger rams
2 — Outrigger supports
3 — Base
4 — Rotation cylinders
5 — Deviator outriggers - crane
6 — Outrigger multifunction deviator
7 — Outrigger multifunction transmission
8 — Distributor bank
9 — Double control
10 — Column
11 — Inner ram
12 — Inner boom
13 — Outer ram
14 — Outer boom
15 — Booms extension rams
16 — Booms extension rams
17 — Lifting hook
18 — Oil tank
19 — Manual extensions (optional)
20 — Seat (optional)
21 — Hand-cables for crane (optional)
— Version with ground controls for outriggers and top seat controls
for crane (fig. 5)
Pos. Description
1 — Outrigger rams
2 — Outrigger supports
3 — Base
4 — Rotation cylinders
5 — Deviator outriggers - crane
6 — Outrigger multifunction deviator
7 — Outrigger multifunction transmission
8 — Column
9 — Seat
10 — Distributor bank
11 — Inner ram
12 — Inner boom
13 — Outer ram
14 — Outer boom
15 — Booms extension rams
16 — Extension boom sections
17 — Lifting hook
18 — Oil tank
19 — Manual extensions (optional)
