Fastech Ezi-Servo ALL

www.fastech.co.kr
98
Appendix
Wiring Diagram
Drive Connector(CN3)
Cable Connection
Motor Connector
Pin Layout
Pin No.
Pin No.
Pin Layout
1
1
2
2
3
3
4
4
Connector Specification
Item
Specification
Maker
Housing
5557-04
MOLEX
Terminal
5556
MOLEX
■ Extension cable for Encoder
Available to extend the distance between the encoder and Ezi-SERVO Plus-R.
Refer to ② of 「5.2 Controller Configuration」.
Wiring Diagram
Drive Connector(CN2)
Cable Connection
Motor Connector
Pin Layout
Pin No.
Pin No.
Pin Layout
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
Connector Specification
Type
Item
Specification
Maker
Drive Connector (CN2)
Housing
Terminal
51353-100
56134-9000
MOLEX
MOLEX
Motor Connector
Housing
Terminal
SMP-09V-NC
SHF-001T-0.8BS
JST
JST
