H1-7
Module Name Specifications
Peripheral and Accessory
RFID Card CARD-H
Read / Write wireless card (for FBs-DAP-BR/CR and FBs-PEPR)
Programming
Devices
FP-08
FBs- Series PLC handheld programmer
Winproladder
FATEK-PLC Winproladder Programming software
Memory Pack FBs-PACK
FBs-PLC program memory pack with 20K Words program, 20K Words register, write protection switch
PWMDA module PWMDA
10-bit single channel pulse width modulation(PWM) 0~10V analog output (AO) module
USB- RS232
Converter Cable
FBs-U2C-MD-180
Communication converter cable with standard USB AM connector to RS232 MD4M connector (used in
standard PC USB to FBs main unit Port 0 RS232), length 180cm
Communication
cables
FBs-232P0-9F-150
MD4M to DB9F communication cable (FBs main unit Port 0 RS232 connect to standard DB9M), length
150cm
FBs-232P0-9M-400
MD4M to DB9M communication cable (FBs main unit Port 0 RS232 connect to DB9F), length 400cm
FBs-232P0-MD-200
MD4M to MD4M communication cable (FBs main unit Port 0 RS232 connect to FBs-PEP/PEPR), length
200cm
FBs-232P0-MDR-200
MD4M to 90˚ MD4M communication cable (FBs main unit Port 0 RS232 connect to FBs-PEP/PEPR),
length 200cm
High density DIO
cable
HD30-22AWG-200
High density modules(FBs-24X, FBs-24YT/J, FBs-32DGI) connector，30pin Socket, 22AWG I/O cable,
length200cm
16/7-Segment
LED display
DBAN.8-nR
0.8” 4-digit 16-segment LED display, n means R(Red) 16-segment LED characters display installed,
can be 1~4
DBAN.2.3-nR
2.3” 4-digit 16-segment LED display, n means R(Red) 16-segment LED characters display installed,
can be 1~4
DB.56-nR
0.56" 8-digit 7-segment display, n means R(Red) 7-segment LED characters display installed,
can be 1~8
DB.8-nR
0.8" 8-digit 7-segment display, n means R(Red) 7-segment LED characters display installed, can be 1~8
DB2.3-nR
2.3" 8-digit 7-segment display, n means R(Red) 7-segment LED characters display installed, can be 1~8
DB4.0-nR
4.0" 4-digit 7-segment display, n means R(Red) 7-segment LED characters display installed, can be 1~4
Training Box
FBs-TBOX
46cm x 32 cm x 16cm suitcase, containing FBs-24MCT main unit. FBs-CM25E communication module
(RS232 + RS485 + Ethernet network), 14 simulated input switches, 10 external relay output, Doctor
terminal outlet I/O, peripherals such as stepping motor, encoder, 7-segment display, 10 of 10mm LED
indicator, thumbwheel switch, and 16 key keyboard.
1. ◇：R ─ Relay output；T ─ Transistor SINK(NPN) output； J ─ Transistor SOURCE (PNP) output
2. ∆：2 ─ built-in RS232 port；U ─ built-in USB port (non-standard)
3. ◎：AC ─ 100~240VAC power supply； D12 ─ 12VDC power supply；D24 ─ 24VDC power supply
4. –C：Blank ─ Standard；–C ─ add in RTC
5. The unmarked frequencies of Digital Input (DI) or Digital Output (DO) are low speed.
