H1-6
Module Name Specifications
Thumbwheel switch
module
FBs-32DGI
8 sets 4 digits (total 32 digits) thumbwheel switch (or 128 points independent switch) multiplex input
module, 30 pins header connector
16/7 Segment LED
display modules
FBs-7SG1
1 set 8 digits 7-segment/4 digits 16-segment LED display (or 64 points independent LED) output display
module, 16 pins header connector
FBs-7SG2
2 sets 8 digits 7-segment/4 digits 16-segment LED display (or 128 points independent LED) output
display module, 16 pins header connector
AIO modules
FBs-2DA
2 channels, 14-bit analog output module (-10~10V, 0~10V or -20~20mA, 0~20mA)
FBs-4DA
4 channels, 14-bit analog output module (-10~10V, 0~10V or -20~20mA, 0~20mA)
FBs-4A2D
4 channels, 14-bit analog input (same specification as 6AD)+2 channels, 14-bit analog output (same
specification as 2DA) combo module
FBs-6AD
6 channels, 14-bit analog input module (-10~10V, 0~10V or -20~20mA, 0~20mA)
Temperature
measurement
modules
FBs-2TC
2 channels, thermocouple temperature input module with 0.1°C resolution.
FBs-6TC
6 channels, thermocouple temperature input module with 0.1°C resolution.
FBs-16TC
16 channels, thermocouple temperature input module with 0.1°C resolution.
FBs-6RTD
6 channels, RTD temperature input module with 0.1°C resolution.
FBs-16RTD
16 channels, RTD temperature input module with 0.1°C resolution.
FBs-6NTC
6 channels, NTC temperature input module with 0.1°C resolution.
AI + Temperature
Measurement
combo modules
FBs-2A4TC
2 channels, 14-bit analog input (same specifications as 6AD)+ 4 channels thermocouple temperature
input (same specifications as 6TC) combo module
FBs-2A4RTD
2 channels, 14-bit analog input (same specifications as 6AD) + 4 channels RTD temperature input (same
s
pecifications as 6RTD) combo module
Voice modules FBs-VOM
Built-in 1MB memory (play continuously up to 2 minutes), extendable 4GB SD card(play continuously up
t
o 8,000 minutes) voice module, 245 messages, output 2W
Load Cell Module FBs-1LC
1 channel, load cell measurement module with 16-bit resolution (including sign bit)
Potential Meter
Module
FBs-4PT
4
channels, 14-bit potential meter input module (Impedance range: 1~10K Ω)
Left Side Expansion Modules
Communication
modules
FBs-CM22
2 ports RS232 (Port3 +Port 4) communication module
FBs-CM55
2 ports RS485 (Port3 +Port 4) communication module
FBs-CM25
1 port RS232 (Port3) + 1 port RS485 (port 4) communication module
FBs-CM25E
1 port RS232 (Port3) + 1 port RS485 (port 4) + Ethernet network interface communication module
FBs-CM55E
1 port RS485 (Port3) + 1 port RS485 (port 4) + Ethernet network interface communication module
FBs-CMZB
Z
igBee communication module
FBs-CMZBR
Z
igBee communication repeate
r
FBs-CMGSM
GSM wireless communication module
FBs-CM25C
General purpose RS232 to RS485/RS422 communication interface converter with photocouple isolation
FBs-CM5R
General purpose RS485 repeater with photocouple isolation
FBs-CM5H
General purpose 4 ports RS485 HUB with photocouple isolation, RS485 can be connected as star
connection
Communication
boards
FBs-CB2
1 port RS232 (Port 2) communication board
FBs-CB22
2 ports RS232 (Port 1+ Port 2) communication board
FBs-CB5
1 port RS485 (Port 2) communication board
FBs-CB55
2 ports RS485 (Port 1+ Port 2) communication board
FBs-CB25
1 port RS232 (Port 1) + 1 port RS485 (Port 2) communication board
FBs-CBE
1 port 10 Base T Ethernet communication board
FBs-CBEH
1 port 100 Base T Ethernet communication board
FBs-CBCAN
1 port CANopen communication board
AIO
boards
FBs-B2DA
2 channels, 12-bit analog output board (0~10V or 0~20mA)
FBs-B2A1D
2 channels, 12-bit analog input + 1 channel, 12-bit analog output combo analog board (0~10V or
0~20mA)
FBs-B4AD
4
channels, 12-bit analog input board (0~10V or 0~20mA)
Precision Load
Cell Module
FBs-1HLC
1 channel, high precision weighing control module with 24-bit resolution
3-Axis Motion
Control Module
FBs-30GM
3-Axis with linear and circular interpolation advanced motional control module, 3 sets of 200KHz high
s
peed pulse input, 3 sets of 500KHz high speed pulse output, 14 points main unit, 16M Bytes program
capacity, 20K Words retentive file register, built-in RS485 and Ethernet, 7.62mm detachable terminal
block
Simple HMI
FBs-BDAP
Board type Data Access Panel
FBs-BPEP
Board type Parameter Entry Panel
FBs-PEP/PEPR
Multi characters with graphics-based Parameter Entry Panel, built-in RFID Read/Write module with PEPR
FBs-DAP-B/BR
16 X 2 LCD character display, 20 keys keyboard, 24VDC power supply, RS485 communication interface,
built-in RFID Read/Write module with BR
FBs-DAP-C/CR
16 X 2 LCD character display, 20 keys keyboard, 5VDC power supply, RS232 communication interface,
built-in RFID Read/Write module with CR
