FATEK FBs-CB2 - Page 203

Advanced Function Instruction
7-39
FUN 59 P
→7SG
7-SEGMENT CONVERSION
FUN 59 P
→7SG
Nibble data of S Low byte of D
Hexadecimal
number
Binary
number
7-segment
display format
B7
z
B6
a
B5
b
B4
c
B3
d
B2
e
B1
f
B0
g
Display
pattern
0 0000 0 1 1 1 1 1 1 0
1 0001 0 0 1 1 0 0 0 0
2 0010 0 1 1 0 1 1 0 1
3 0011 0 1 1 1 1 0 0 1
4 0100 0 0 1 1 0 0 1 1
5 0101 0 1 0 1 1 0 1 1
6 0110 0 1 0 1 1 1 1 1
7 0111 0 1 1 1 0 0 1 0
8 1000 0 1 1 1 1 1
1
1
9 1001 0 1 1 1 1 0 1 1
A 1010 0 1 1 1 0 1 1 1
B 1011 0 0 0 1 1 1 1 1
C 1100 0 1 0 0 1 1 1 0
D 1101 0 0 1 1 1 1 0 1
E 1110 0 1 0 0 1 1 1 1
F 1111
B1
B2
B6
B5
B4
B0
B3
B7
P
a
f
e
c
g
b
d
0 1 0 0 0 1 1 1
7-segment display pattern table
