Advanced Function Instruction
7-80
FUN 94
ASCWR
ASCII WRITE
FUN 94
ASCWR
z Interface signals:
M1927: This signal is control by CPU, it is applied in ASCWR MD:0
: ON, it represents that the RTS (connect to the CTS of PLC) of the printer is “False”.
I.e. the printer is not ready or abnormal.
: OFF, it represents that the RTS of the Printer is “True”; Printer is Ready.
Note: Using the M1927 associates with timer can detect if the printer is abnormal or not.
R4158: The setting of communication parameters (refer to section 11.7.2)
