Appendix -3
case, the DAP shall be reset).
11、 Versions after the OS V3.15 (including) of FP-07 can be aimed for DOCs in 16 words of contacts, registers.
1.3 The Main Functions of FB-DAP
The main functions of FB-DAP can be categorized as： setter functions of general information, FUN functions of
parameter setting, wireless card reading, and message display function. The details of the functions will be introduced in
the following sections.
1.4 Setter Functions of General Information
FB-DAP can be used as a 〝TC setter〞as well as the access to registers (R、D、W) and contacts (X、Y、M、
S). In the FUN functions in the following sections, it can also be used as write-protect with T、C、R、D、X、Y、M、S. There
are two measures to monitor information: ADR (general addresses) and DOC monitoring. The latter shall make DOC
compilation (16 words in English, symbols, numbers) in advance through Proladder or FP07 for T, C, register R/D and
contacts so the DOC can be displayed.
1、 ADR Monitoring
A. Timer and Counter Monitoring
【Pressing Keys】：
or number
T or C number Cursor position
↓
← Set value
← Current value
↑ ↑
Status FB-DAP automatic detecting a decimal point position
B. Registers (R、D、DR、DD、WX、WY、WM、WS) and contacts (X、Y、M、S) monitoring
【Monitored range】
Type
T C D R DD DR WX WY WM WS X Y M S
Range
0
|
255
0
|
255
0
|
2943
0
|
8071
0
|
2492
0
|
8070
0
|
240
0
|
240
0
|
1984
0
|
984
0
|
255
0
|
255
0
|
2001
0
|
999
【Pressing keys】：
+
(
(
+ ( )
)
)
or
or
or or or
or or or
number
+
Cursor position Value
↓ ↓
← Item 1
← Item 2
↑
Status
   
  
 
 
