Chapter 2: Motherboard information
Connectors/Jumpers/Slots
Page
1.
Chassisfanconnectors(4-pinCHA_FAN1) 2-15
2.
PS/2keyboardandmouseconnector(KBMS1) 2-22
3.
Minicardconnector(MINI_CARD1,MINI_CARD2) 2-19
4.
Frontpanelaudioconnector(10-1pinAAFP1) 2-15
5.
Audioamplierconnector(4-pinAMP_CON) 2-23
6.
Digitalaudioconnector(4-1pinSPDIF_OUT) 2-24
7.
Serialportconnectors(10-1pinCOM2,COM3,COM4) 2-21
8.
DigitalI/Oconnector(DIO1) 2-20
9.
USB2.0connector(10-1pinUSBHUB_34,USBHUB_56 2-19
10. VGAconnector(16-pinVGA1) 2-22
11.
LVDSconnector(30-pinLVDS1) 2-18
12.
Invertervoltageselection(3-pinJ2) 2-9
13.
Backlightinverterpowerconnector(5-pinINV1) 2-18
14.
LVDSpanelvoltageselection(3-pinJ4) 2-10
15.
Systempanelconnector(10-1pinF_PANEL) 2-16
16.
ClearRTCRAM(CLRTC) 2-8
17.
SerialATA3.0Gb/sconnectors(7-pinSATA3G_1,SATA3G_2) 2-17
18.
StandbyPowerLED(SB_PWR_LED1,Main_PWR_LED2) 2-11
19.
CPUInverterbacklightcontrolofinverterselector(3-pinJ3) 2-10
20.
SATApowerconnector(SATA_PWR1) 2-17
21. SO-DIMMmemoryslots 2-6
22. Intel
®
J1900/N2807CPU 2-6
23. 12VDCconnector(2-pinEATX_PWR1) 2-14
24. COM1Ring/+5V/+12Vselection(6-pinJ1) 2-9
25. Batteryconnector(2-pinBATTERY1) 2-23
26. BIOSprogrammableconnector(8-pinSPI) 2-20
27. DisplayPortheader(16-pinDP_Head1) 2-24
