Faytech FAY-002 - 3.3.2 CPU Configuration; 3.3.3 Super IO Configuration; 3.3.4 Dynamic Digital IO

3-4
FAY-002
The following items appear when Wake System with Dynamic Time is
enabled.
Wake up minute increase [1]
Specify the number of minutes added to the current time before waking up
system.
3.3.2 CPU Configuration
The items in this menu show CPU-related information.
Socket 0 CPU Information
Displays additional CPU information.
Intel Virtualization Technology [Enabled]
[Enabled] Allows a hardware platform to run multiple operating systems
separately and simultaneously, enabling one system to
virtually function as several systems.
[Disabled] Disables this function.
3.3.3 Super IO Configuration
Serial Port1~4 Configuration
The sub-items in this menu allow you to set the serial port conguration.
Serial Port [Enabled]
Allows you to enable or disable the serial port (COM). Configuration options:
[Enabled] [Disabled]
The following item appears only when you set Serial Port to [Enabled].
Change Settings [Auto]
Allows you to select the Serial Port base address. Conguration options:
[Auto] [IO=3F8h; IRQ=4] [IO=3F8h; IRQ=3,4;] [IO=2F8h; IRQ=3,4;] [IO=3E8h;
IRQ=3,4;] [IO=2E8h; IRQ=3,4;]
3.3.4 Dynamic Digital IO
The items in this menu allow you to modify Digital IO settings.
Pin 0~7 [Output]
Set pin 0~7 data ow as Input or Output. Conguration options: [Input] [Output]
