2-14
IMPORTANT:
• WerecommendthatyouuseaPSUwithhigherpoweroutputwhen
conguringasystemwithmorepower-consumingdevices.Thesystem
may become unstable or may not boot up if the power is inadequate.
2.8.2 Internal connectors
1. 12VDC power connectors (2-pin PWR1)
Thisconnectorisfora12VDCpowersupply.Pleasebecarefultoconnectthe
PINright—awrongpolaritywillleadtoahardwaredefectofthemainboard.
FAY-002 ATX power connector
PWR1
PIN 1
+12VSUS
GND
