Chapter 2: Motherboard information
CAUTION: Do not forget to connect the fan cables to the fan connectors.
Insufcientairowinsidethesystemmaydamagethemotherboard
components.Thesearenotjumpers!Donotplacejumpercapsonthefan
connectors!
2. Chassis fan connectors (4-pin CHA_FAN1)
Connectthefancablestothefanconnectorsonthemotherboard,ensuring
that the black wire of each cable matches the ground pin of the connector.
FAY-002 Fan connector
CHA_FAN
+5VS
SENSE
12VS
GND
3. Front panel audio connector (10-1 pin AAFP)
Thisconnectorisforachassis-mountedfrontpanelaudioI/Omodulethat
supportseitherHDAudioorlegacyAC`97audiostandard.Connectoneend
ofthefrontpanelaudioI/Omodulecabletothisconnector.
IMPORTANT:Werecommendthatyouconnectahigh-denitionfrontpanel
audiomoduletothisconnectortoavailofthemotherboard’shigh-denition
audio capability.
FAY-002 Front panel audio connector
AAFP1
AGND NC MIC1-JD LINE1-JD
A_MIC1_L
A_MIC1_R
LINEIN-R
A_JD_FRONT
LINEIN-L
PIN1
