2-17
Chapter 2: Motherboard information
6. SATA power connector (4-pin SATA_PWR1)
ThisconnectorisfortheSATApowercable.Thepowercableplugis
designedtotthisconnectorinonlyoneorientation.Findtheproper
orientationandpushdownrmlyuntiltheconnectorcompletelyt.
FAY-002 SATA POWER connector
SATA_PWR1
+5V GND GND +12V
PIN1
IMPORTANT:TheSATApowerconnectorsupports1Acurrenttothe
maximum.
5. Serial ATA 3.0Gb/s connectors (7-pin SATA3G_1)
TheseconnectorsconnecttoSerialATA3.0Gb/sharddiskdrivesand
opticaldrivesviaSerialATA3.0Gb/ssignalcables.
NOTE:
• YoumustinstallWindows®XPServicePack3orlaterversionbeforeusing
SerialATAharddiskdrives.
• Whenusinghot-plugandNCQ,settheSATAModeSelectioniteminthe
BIOSto[AHCI].Seesection3.3.7 IDE Configuration for details
FAY-002 SATA 3.0Gb/s connectors
SATA3G_2
GND
S_SA3_RXP2_C
S_SA3_RXN2_C
GND
S_SA3_TXN2_C
S_SA3_TXP2_C
GND
SATA3G_1
GND
S_SA3_TXP1_C
S_SA3_TXN1_C
GND
S_SA3_RXN1_C
S_SA3_RXP1_C
GND
