Chapter 1: General information
DISPLAY
Chipset
Intel® Graphics Media Accelerator
Resolution
Up to 1920x1200@60Hz for VGA
Up to 1920x1200@60Hz for DisplayPort
Up to 1920x1200@60Hz, Dual Channel 24-bit (via CH7511) for
LVDS
Output interface
1 x LVDS
1 x VGA
1 x DisplayPort
I/O
Rear I/O (low profile)
1 x DP (horizontal)
2 x LAN (RJ45) port
1 x USB2.0 connector (blue) (top) and 1 x USB 3.0 connector (blue)
(bottom)
2 x USB 2.0 connector (black)
1 x COM (RS232/422/485; RI / 5V / 12V)
1 x screw type DC power port (12V)
Internal I/O
1 x 12V DC Power Connector (2 pin)
1 x Chassis Fan connector (4 pin)
2 x SATA connector (standard, 7 pin)
1 x SATA power connector (4 pin)
2 x Full / Half Size Mini Card slots with PCIe and USB interface (one with
mSATA optional by BOM*)
4 x USB2.0 (2 box header, 10 pin)
3 x RS232/422/485 header (10 pin)
1 x DisplayPort header (16 pin) colay with DP on rear IO
1 x VGA connector (16 pin)
1 x LVDS connector (30 pin)
1 x Backlight inverter power connector (5 pin)
1 x Front Panel audio connector (10-1 pin)
1x4pinAmplierconnectorpinheader(5pin,k5,2.00mm)
1 x Line-out / Mic-in pin header (10-1 pin)
1 x SPDIF Output pin header (4-1 pin)
1 x DIO connector (10 pin)
1 x PS/2 Keyboard Mouse Connector (6 pin)
*Please check the „Optional mSATA Manual“ for further instructions.
