Flow Rate Adjustment
•Turning Clockwise
-Increases flow rate
•Turning Counter Clockwise
-Decreases flow rate
10
Syrup Flow
Adjustment
Water Flow
Adjustment
Front View
Top View
Water Inlet
Solution Outlet
Syrup Inlet
Tank Pressure
Transducer
Sample Outlet
Sample Valve
Syrup
Pressure
Transducer
Water Pressure
Transducer
Solution Mixing Module
