FBD 564 - Navigation System and Keypad Functions

Navigation System
33
•The keypad is used to operate machine and navigate through operation menus. Key functions are
listed below
FILL:
Activates and deactivate solution and CO2 solenoid to fill barrel
BEATER:
Activates and deactivate the beater motor
BEFROST:
Activates and deactivate DEFROST cycle
RUN:
Activates machine to self
sustaning running cycle
OFF:
Deactivates machine from self
sustaning running cycle
CANCEL:
Exits function menus without making changes
BACK:
Scrolls to left of menu &
decreses value in settings
FORWARD:
Scrolls to right of menu & increases value in settings
SELECT:
Selects
changing value, finalizes value changes and enters into sub menus
BLANK BUTTON:
Enters into the service menus
