FBD 564 - Expansion Adjustment

Expansion Adjustment
42
Expansion setting is used to increase or decrease Refill and Full pressure. Table below
demonstrates the effects of change in Refill and Full pressure
•Higher Barrel pressure represents higher expansion
•Lower Barrel pressure represents lower expansion
EXPANSION SETTINGS
VALUE REFILL FULL
Recommended Active Charge Pressure
0 22.5 24.5 26
1 23 25 26.5
2 23.5 25.5 27
3 24 26 27.5
4 24.5 26.5 28
5 25 27 28.5
6 26 27.5 29
