Basic Troubleshooting Chart
Symptom Possible Cause Action
Low ow or low
pressure
Restriction in inlet or
discharge pipes
- Check pump inlet pressure
- Check position of all control valves
- Check throttle valve is fully open
Incorrect pump
speed or direction
- Check VFD for proper speed setting (if equipped).
- Check power supply frequency (50 or 60 Hz)
- Check rotational direction of motor
Gauges not operat-
ing properly
- Inspect gauges for proper operation.
Air Leaks (vacuum
on pump inlet)
- Inspect inlet piping joints for leaks
- Inspect pump mechanical shaft seal for leaks
Pump cavitation - Check inlet pressure during operation
- Check for excessive ow rate
Air in casing - Purge air from all piping
Internal damage - Inspect balance disc for damage
- Inspect HPSC vent line for restrictions (if
equipped)
Design parameters - Pump not designed for operating conditions
Pump vibration or
noise
Operating conditions - Pump cavitation
- Excessive ow rate
- Insu󰀩cient ow rate
Pump misalignment - Inspect alignment (Refer to Final Pump Alignment)
Balance disc - Inspect balance disc for damage
- Inspect HPSC vent line for restrictions (if
equipped)
Pump Leaks Pipe Joints - Inspect pipe joints for insu󰀩cient sealing
Pump Shell - Inspect pump stage joints for damaged O-rings
Pump Shaft - Inspect mechanical seal for leakage
- Inspect pump shaft for misalignment
Motor runs hot, is
noisy or shuts o󰀨
Excessive Motor
Load
- Check voltage supply for consistency
- Check ambient air temperature
- Check wiring and fuses for phase loss
- Check ow rate and VFD settings (if
Equipped).
- Check wiring length between motor and VFD
(if equipped).
- Check motor bearings
NOTES: Contact motor manufacturer for proper
repair procedures.
