Fedders R407C - Page 7

E
E
E
E
1
H
1
H
F
F
F
F
E
E
E
E
4
4
4
4
1
1
2
2
8
8
4
4
N
N
N
N
Item
6
6
6
6
No.
Description
Service Part #
D
D
D
D
-----CHASSIS ASSEMBLY-----
1 Lock Plate, Blower Wheel Left 36-08-00010-001 1 1 1 1
2 Lock Plate, Fan Motor, Right 36-08-00020-001 1 1 1 1
3 Lock Plate, Fan Motor, Left 36-08-00030-001 1 1 1 1
4 Motor, Discharge Cover 36-08-00050-001 1 1 1 1
5 Plate protect, Coil Water 36-08-00060-001 1 1 1 1
6 Tube Bracket 36-08-00070-001 1 1 1 1
7 Base Asm. 36-08-00080-001 1 1 1 1
(include PS base, reinforce plate
and insulation)
8 Fan Motor 35-16-90010-001 1 1 1 1
9 Grommet, Fan Motor 36-08-00100-001 2 2 2 2
10 Blower Wheel, Dia102x763lg, Antimould 36-08-00110-002 1 1 1 1
11 Blower Wheel Grommet Asm 36-08-00120-001 1 1 1 1
(include grommet, bearing)
12 Drip Tray 36-08-00130-001 1 1 1 1
(include PS and PE insulation
complete)
13 Air Deflector 36-08-00140-001 14 14 14 14
14 Handle Air Deflector 36-08-00150-001 2 2 2 2
15 Tie-bar, Air Deflector 36-08-00160-001 2 2 2 2
16 Discharge Cover 36-08-00170-001 1 1 1 1
17 Bearing, Discharge Cover, Mid 36-08-00180-001 2 2 2 2
18 Bearing, Discharge Cover, Left 36-08-00190-001 1 1 1 1
20 Plug, Drip Tray 36-08-00210-001 1 1 1 1
21 Drain Hose Asm. 36-08-00220-001 1 1 1 1
(include drain hose,insulation)
22 Decorative Front Grille,Neuter 36-08-00230-N01 1 1 1 1
23 Decorative Front Top Cover 36-08-00240-N01 1 1 1 1
INDOOR EVAPORATOR UNIT
(R407C)
MODEL NUMBER
FEDDERS
LARGE SPLIT
B2
