Fedders R407C - Page 8

E
E
E
E
1
H
1
H
F
F
F
F
E
E
E
E
4
4
4
4
1
1
2
2
8
8
4
4
N
N
N
N
Item
6
6
6
6
No.
Description
Service Part #
D
D
D
D
INDOOR EVAPORATOR UNIT
(R407C)
MODEL NUMBER
FEDDERS
LARGE SPLIT
-----CHASSIS ASSEMBLY(Cont')-----
24 Filter 35-16-00010-001 2 2 2 2
NI 3M Purifying Filter 35-03-01460-001 1 1 1 1
NI Charcoal Purifying Filter 35-03-00260-001 1 1 1 1
25 Lens, Sensor 36-08-00250-001 1 1 1 1
26 Cover, Screw 36-08-00260-001 3 3 3 3
27 Label, LED Lens 36-08-00270-001 1 1 1 1
-----REFRIGERANT ASSEMBLY-----
28 Evaporator Coil Asm. 37-16-08540-001 1 1 1 1
(include flare fittings, top, bottom &
back coil Asm., connecting
tubes)
-----ELECTRICAL ASSEMBLY-----
29 Metal Cover, Electical Box 36-08-00280-001 1 1 1 1
30 Metal Cover, Terminal Connection 36-08-00290-001 1 1 1 1
31 Base, Main PCB 36-08-00300-001 1 1 1 1
32 Electrical Box 36-08-00310-001 1 1 1 1
33 Cover, Electical Box 36-08-00320-001 1 1 1 1
34 Cover, Terminal Connection 36-08-00330-001 1 1 1 1
35 Strain Relief, Interconnect 36-08-00340-001 1 1 1 1
36 Metal Electrical Box Asm 36-08-00350-001 1 1 1 1
37 Electrical Box, Front 36-08-00360-001 1 1 1 1
38 Holder, Receiver 36-08-00370-001 1 1 1 1
NI Mount Plate, Terminal Block 35-16-00030-001 1 1 1 1
NI Terminal Block ,9P 35-03-00540-031 1 1 1 1
39 Cover, LED 36-08-00380-001 1 1 1 1
40 Base, LED 36-08-00390-001 1 1 1 1
B3
