Fedders R407C - Page 9

E
E
E
E
1
H
1
H
F
F
F
F
E
E
E
E
4
4
4
4
1
1
2
2
8
8
4
4
N
N
N
N
Item
6
6
6
6
No.
Description
Service Part #
D
D
D
D
INDOOR EVAPORATOR UNIT
(R407C)
MODEL NUMBER
FEDDERS
LARGE SPLIT
-----ELECTRICAL ASSEMBLY(Cont')-----
41 Main P.C. Board (C/O) 35-16-04160-012 1 -- 1 --
41 Main P.C. Board Kit (H/P) 50-18-0015N-001 -- 1 -- 1
(Includes LED, Receiver PCB,
All Thermisters, Cables)
42 LED PC Board 35-16-04110-011 1 1 1 1
43 Receiver PC Board 35-16-04120-011 1 1 1 1
44 Wiring Diagram (C/O) 36-08-00420-001 1 -- 1 --
44 Wiring Diagram (H/P) 36-08-00430-001 -- 1 -- 1
NI Power Cord 36-08-00440-001 1 1 1 1
46 Strain Relief, Power Cord 36-08-00450-001 1 1 1 1
NI Clip, Thermistor 35-03-01280-001 1 1 1 1
NI Spring, Thermistor 35-05-00200-001 1 1 1 1
NI Indoor Air Thermistor,10K 35-11-04140-03K 1 1 1 1
NI Indoor Coil Thermistor,10K 35-11-04110-03K 1 1 1 1
NI Outdoor Coil Thermistor, 10K 35-11-04120-03K -- 1 -- 1
NI Jumper, Outdoor Thermistor 35-16-04170-011 -- 1 -- 1
-----PACKAGING PARTS-----
48 Mounting Bracket, Unit 36-08-00460-001 1 1 1 1
49 Remote Control (C/O),Neuter 11-23-03640-020 1 - 1 -
49 Remote Control (H/P),Neuter 11-23-03640-021 - 1 - 1
50 Remote Control Holder 35-02-00070-01V 1 1 1 1
51 Packaging Clam Shell 36-08-00400-001 2 2 2 2
52 Carton,Neuter 36-08-00410-001 1 1 1 1
54 Accessory Kit Carton 35-03-00320-001 1 1 1 1
NI Unit Plastic Bag 35-08-01140-001 1 1 1 1
57 Signal/Thermistor Wire 15M,OD 35-02-01170-02K - 1 - 1
NI User Manual 35-03-01350-001 1 1 1 1
NI Installation Manual 35-24-00130-001 1 1 1 1
B4
