Federal RSSM360 - DROP-IN UNITS after 01;01;20

DROP-IN UNITS AFTER 01/01/2020
RSSM360-6, RSSM460-6
MODEL
INTERIOR
VOLUME
CUFT
39.00 X 32.50 X 60.25 10 X 34
991 X 826 X 1530 254 X 864
50.00 X 32.50 X 60.25 10 X 45
1270 X 826 X 1530 254 X 1143
12.46
9.27
DIMENSIONS
L X W X H in
L X W X H mm
RSSM360
SHELVING
L X W in
L X W mm
2 TIER
2 TIER
RSSM460
2-WIRE + GROUND
208-240/60/1
MAX FUSE SIZE
REFRIGERANT
C.U.
HP
APPROXIMATE
CASE WEIGHT
OPTIONAL
CORD & PLUG
NEMA
2-WIRE + GROUND
208-240/60/1
MAX FUSE SIZE
REFRIGERANT
BTU'S
@+20°
APPROXIMATE
CASE WEIGHT
600 LBS 550 LBS
272 KILO 249 KILO
700 LBS 650 LBS
317 KILO 295 KILO
15 AMPS
15 AMPS
REMOTE
SELF CONTAINED
NEMA 6-20P
R449a
1/2HP
R449a
5400
7500
NEMA 6-20P
R449a
20 AMPS
3/4HP
R449a
20 AMPS
BACK VIEW
FRONT VIEW
PLAN VIEW
J
R
R
SIDE VIEW
J
NOTE: THIS UNIT IS SUPPLIED WITH
1) REAR CONDENSER AIR INTAKE & DISCHARGE.
2) REAR MOUNTED CONTROLS
3) CONDENSER AIR FILTER REMOVABLE & CLEANABLE
REFRIGERATION CONTROL
MAIN POWER SWITCH
CONDENSER AIR DISCHARGE
BOTH SIDES
CONDENSER AIR INTAKE
REMOVABLE GRILLE
CLEANABLE FILTER
60.25
25.12
L
DRAIN
REFRIGERATION
LINES
MAIN POWER
JCT BOX
CONDENSER
AIR INTAKE
CONDENSER
AIR DISCHARGE
CONDENSER
AIR DISCHARGE
2.00
2.00
COUNTER TRIM
ELECTRICAL
CONNECTION
NIGHT CURTAIN
TOP LIGHT
&
LIGHT SWITCH
After 01/01/2020 no counter front cutout required case is vented from the back.
Rear counter cutout required for control & filter access.
Refrigerated Self-Serve Merchandiser (High Profile) Page 23
