LEVELING CASE
The drop-in cases are equipped with adjustable leg levelers with 2” adjustment for leveling the case
with the counter. Blocking may need to be added under the leg levelers for support.
DUCTING CONDENSER AIR INTAKE
Ducting is REQUIRED on the inside of the cabinet between the inner front wall of the cabinet and the
base front panels as shown in the diagram above. This is needed to prevent warm condenser air from
recirculating thru the condenser coil. If this is not done it will affect case temperature performance,
shorten the life of the compressor and void the compressor warranty.
