4. Technical Parameters
Panel Size
5.7 inch IPS
Resolution
1920 x 1080 pixels
Dot Pitch
0.0657 (H) x 0.0219 (W)mm
Aspect Ratio
16:9
Brightness
460cd/㎡
Contrast
1400:1
Viewing Angle
85°/85°(L/R) 85°/85°(U/D)
Backlight
LED
Input Signal
HDMI
output Signal
HDMI
HDMI Input / Output
Support Format
480i /480p /576i /576p
720p(60/59.94/50/30/29/25/24/23.98)
1080i(60/59.94/50)
1080p(60/59.94/50/30/29.97/25/24/24sF/23.98/23.98sF)
4K UHD 3840×2160p (30/29.97/25/24/23.98 Hz)
4096×2160p (24Hz)
Headphone Output
stereo 3.5mm
Input Voltage
DC: 7~24V
Power Consumption
≦8W
Unit Size (mm)
148Lx82Hx18.6D (mm)
Unit Weight
280g/310g (With F970 Battery Plate)
Installation Method
1/4 inch bracket screw holes, can be easily connected to
the hot shoe mount, tripod fixed installation
Working Temperature
- 20℃～55℃
Storage Temperature
- 30℃～65℃
